Unnamed: 21	12,65 kg
Tolerance	G7
Length of Carriage	365 mm
Total Height	145 mm
Total Width	260 mm
Width of Carriage	250 mm
Tolerance h7	32 mm
Maximum length of Support Rail	6.000 mm
Tolerance P9	10 mm
Length of Keyway	32 mm
Depth of Keyway	5 mm
Depth of Thread	15 mm
Safety Distance	85 mm
Maximum Speed	5 m/s
Maximum Acceleration	30 m/s2
Load direction I: compressive load	324.000 N
Load direction II: tensile load	180.000 N
Load direction III: lateral load	188.000 N
Max. permissible static moment per Carriage 1	8.500 Nm
Geometrical moments of inertia of Support Rail	899 cm4
Depth Fit	4 mm
Width of Return Unit	263 mm
Height of Return Unit	120,5 mm
Length of Wiper Brushes	6 mm
Minimum operating Temperatur	0 °C
Maximum operating Temperatur	80 °C
Mass of additional Carriage	12,65 kg
Height of Support Rail	108 mm
Support Rail Design	/
Length of Return Unit	115,5 mm
