Unnamed: 21	150 mm
Length of Carriage	365 mm
Total Height	145 mm
Total Width	260 mm
Width of Carriage	250 mm
Maximum length of Support Rail	5.850 mm
Width of End Plates	259 mm
Effective length factor of bellow	1,18
Height of Carriage	35 mm
Width of Support Rail	108 mm
Safety Distance	10 mm
Mass of Carriage	11,28 kg
Load direction I: compressive load	324.000 N
Load direction II: tensile load	180.000 N
Load direction III: lateral load	188.000 N
Max. permissible static moment per Carriage 1	15.500 Nm
Geometrical moments of inertia of Support Rail	899 cm4
Mass of additional Carriage	11,28 kg
Minimum distance between the Carriages	20 mm
Second, non-driven Carriage	ja
