Unnamed: 21	52,1 mm
Length of Carriage	200 mm
Total Height	110 mm
Total Width	88 mm
Width of Carriage	86 mm
Maximum length of Support Rail	5.850 mm
Width of End Plates	87 mm
Effective length factor of bellow	1,17
Width of Support Rail	90 mm
Safety Distance	10 mm
Mass of Carriage	1,69 kg
Load direction I: compressive load	54.000 N
Load direction II: tensile load	54.000 N
Load direction III: lateral load	54.000 N
Max. permissible static moment per Carriage 1	1.200 Nm
Geometrical moments of inertia of Support Rail	219 cm4
