Основные
Вес	2,8 kg/m
Конструктивный размер	40 mm
Unnamed: 21	3 mm
Высота	35,5 mm
Длина	130 mm
Tolerance	H7
Lower Tolerance	0 mm
1	4 mm
Total Width	40 mm
Width of Carriage	38 mm
Thread	M5
Maximum length of Support Rail	2.000 mm
Length of Keyway	10 mm
Depth of Thread	8 mm
Mass of Carriage	0,25 kg
Maximum Speed	4 m/s
Maximum Acceleration	20 m/s2
Load direction I: compressive load	400 N
Load direction II: tensile load	400 N
Load direction III: lateral load	1.000 N
Geometrical moments of inertia of Support Rail	7,7 cm4
Ø Inner Fit	25 mm
Tolerance ±0,2	70 mm
Width of Keyway	3 mm
Depth Fit	3 mm
Minimum operating Temperatur	0 °C
Maximum operating Temperatur	80 °C
Depth of Keyway, Tolerance P9	1,8 mm
Upper Tolerance	0,2 mm
Max. permissible static moment per Carriage 2	9 Nm
