Основные
Конструктивный размер	85 mm
Unnamed: 21	3 mm
Высота	70 mm
Длина	298 mm
Tolerance	H7
Total Width	65 mm
Width of Carriage	63 mm
Thread	M6
Length of Keyway	25 mm
Depth of Thread	14 mm
Height of Carriage	14,2 mm
Mass of Carriage	1,4 kg
Maximum Speed	8 m/s
Maximum Acceleration	40 m/s2
Load direction I: compressive load	5.400 N
Load direction II: tensile load	5.400 N
Load direction III: lateral load	2.500 N
Max. permissible static moment per Carriage 1	255 Nm
Geometrical moments of inertia of Support Rail	107 cm4
Tolerance ±0,2	80 mm
Width of Keyway	5 mm
Depth Fit	1,6 mm
Minimum operating Temperatur	0 °C
Maximum operating Temperatur	80 °C
Depth of Keyway, Tolerance P9	3 mm
Mass of additional Carriage	1,4 kg
Length of Shaft Support Block without drive System	9,3 mm
