Основные
Unnamed: 21	122 mm
Length of Carriage	230 mm
Total Height	84 mm
Total Width	230 mm
Thread	M12
Depth of Thread	34 mm
Effective length factor of bellow	1,28
Height of Carriage	80 mm
Safety Distance	0 mm
Mass of Carriage	10,3 kg
Maximum Speed	5 m/s
Maximum Acceleration	50 m/s2
Load direction I: compressive load	17.600 N
Load direction II: tensile load	17.600 N
Load direction III: lateral load	17.600 N
Max. permissible static moment per Carriage 1	876 Nm
Minimum operating Temperatur	0 °C
Maximum operating Temperatur	80 °C
Length of Bellows Fastener	22 mm
Width of Shaft Support Blocks	230 mm
Height of Shaft Support Blocks	80 mm
Length of Shaft Support Blocks	30 mm
Ø Shaft, Tolerance h7	40 mm
