Unnamed: 21	96 mm
Total Height	77 mm
Total Width	180 mm
Tolerance h7	30 mm
Thread	M12
Depth of Thread	26 mm
Mass of Carriage	4,4 kg
Maximum Speed	5 m/s
Maximum Acceleration	20 m/s2
Load direction I: compressive load	12.000 N
Load direction II: tensile load	7.600 N
Load direction III: lateral load	8.970 N
Minimum operating Temperatur	0 °C
Maximum operating Temperatur	80 °C
Max. permissible static moment per Carriage 2	345 Nm
Length of carriage	180 mm
Height of carriage	60 mm
Maximum length	6.000 mm
Load direction III: lateral load 1	10.700 N
