Основные
Unnamed: 21	152 mm
Total Height	115 mm
Total Width	280 mm
Tolerance h7	50 mm
Thread	M16
Depth of Thread	18 mm
Mass of Carriage	16,3 kg
Maximum Speed	0,15 m/s
Maximum Acceleration	2,5 m/s2
Load direction I: compressive load	26.400 N
Load direction II: tensile load	16.800 N
Load direction III: lateral load	30.320 N
Load capacity fixed Spindle bearing stat	5.530 N
Spindle Diameter	32 mm
Spindle Pitch	6 mm
Mass moment of inertia of threaded Spindle	5,45 kg*cm2
Tolerance ±0,2	62 mm
Minimum operating Temperatur	0 °C
Maximum operating Temperatur	80 °C
Height of Shaft Support Blocks	88 mm
Tolerance g7	72 mm
Length of Shaft Support Block with Drive System	42 mm
Length of Shaft Support Block without drive System	30 mm
Load capacity Spindle Nut stat 3	5.530 N
Length of carriage	280 mm
Height of carriage	93 mm
Maximum length	2.900 mm
Safety distance	6 mm
Diameter drive shaft, Tolerance h7 1	16 mm
Load direction III: lateral load 2	22.600 N
Max. permissible static moment per Carriage 3	1.250 Nm
